CNC Turning Services
Tolerance Masters carries out CNC live tool turning to produce precision parts with a variety of features.
Our turning equipment features an 18″ chucking capacity with a three-jaw chuck capability, and up to 42″ between centers. We offer live tool capability on 2-axis with CNC, bar feed and large swing capabilities.
Part features that we can machine include internal and external threading, splining, contour, form, taper and straight turning. We offer tapping, profiling, pocketing, and other tool functions as well. Working to tolerances of ± .0005″diametrically, we can produce almost any precision part.
CNC TURNING SPECIFICATIONS
Intended Applications
| Machine components Engine components Turbine components Hydraulic Turbomachinery components Construction equipment Shafts Forgings Valves |
Pins Thread rod Fasteners Spindles Sockets Bushings Spacers Fittings Standoffs |
Part Diameter
| Max: 18 in |
Machining Processes
| Parting/Cutting Facing Turning: Contour Turning Form Turning Taper Turning Straight Turning Threading External Internal |
Internal Forming Boring Drilling Counterboring Countersinking Pocketing Profiling Reaming Tapping |
Machinery Axis
| 2 |
Tolerance (+/-)
| Straightness: ±.0005 |
Materials (Metals)
| Alloy Steels Aluminum Beryllium Brass Bronze Alloys Carbide Carbon Steel Cobalt Copper Iron Lead |
Magnesium Molybdenum Nickel Palladium Stainless Steel Stellite (Hardfacing) Tin Titanium Tungsten Zinc |
Materials (Plastic Polymers)
| ABS (Acrylonitrile Butadiene Styrene) Acetal Acrylic Fiberglass Reinforced Plastics Nylon Phenolic Polyamide-Imide Polycarbonate Polyetheretherketone (PEEK) |
Polyetherimide Polyethylene Polyphenylene Sulfide Polypropylene Polystyrene Polysulphone PTFE (PolyTetraFluoroEthylene) PVC (Polyvinyl Chloride) PVDF (Polyvinylidene Fluoride) |
Equipment
| Lathe CNC |
Fixturing
| Three-jaw chuck In-House Fixturing & Tooling |
Equipment Capabilities
| CNC Control Capabilities Large Swing Lathe Bar Feed Milling |
CAD Design Services CAM Programming Services Reverse Engineering |
Secondary Services Offered
| Assembly Drilling Deep hole Drilling Tapping Bending Threading Broaching Counter Sinking Pressing Milling |
Reaming Welding Plating Passivating Etch and Chromating Heat Treating Centerless Grinding Anodizing Inserting Plastic Molding |
Advantages of Turning
| Tight tolerances Short lead times Materials compatible |
Production Volume
| Specialty Production Shop Prototype Low Volume Small Run |
High Volume Large Run Long Run Large Scale Production Volume Run |
Lead Times Available
| Quoted on job by job basis |
Additional Information
Industry Focus
| Aerospace Dental Machine Tool Marine |
Medical Military Optical |
Industry Standards
| ASTM AS9100D Aerospace Industry Standard |
ISO 9001:2008 International Organization for Standardization |
File Format
| .asm .bmp .CATPart .CATProduct .cgr .ckd .ckt .csv .dib .dwg .dxf .exp .gif .hmf .hsf .iges .igs .ipt .jpg .KVTSession CAD |
.mod .model .obj .pm .prt .ptn .sab .sat .session .sldprt .srf .step .stl .stp .tif .u3d .xmt_text x_b x_t xmt_bin |
